Description
- Chamber Type/Size: T18
- Service Chamber Joint Type: Single Clamp Band
- Stud Thread Size: M16 x 1.5-6g
- Mounting Stud Length: 1.70 in (43.2 mm)
- Stud Spacing: 4.75 in (120.7 mm)
- Stroke: 2.50 in (63.5 mm)
- Push Rod Thread/Style: Spherical End
- Push Rod Length (mm): 15 mm
- Service Port (11) - Side: 3/8-18 NPTF
- Port Angle: All Open
- Clamp Angle: 310°
- Service Chamber Vent Holes: 90°
- Maximum Operating Temperature: 176 °F (80 °C)
- Minimum Operating Temperature: -50 °F (-45 °C)
- Cautionary Note(s): All Vent Holes Must Be Open
